This Article Will Bring The Installation Of Pvc Rigid Sheet And Aluminum Foil Roll Of Blister Packaging Machine For Rich Packing Customers:

Remove The Compression Nut And Stop Sleeve On The Film Reel, Put The Pvc Hard Film Or Aluminum Foil Roll On The Adjustment Sleeve, Install The Stop Sleeve And The Compression Nut And Tighten The Compression Nut To Make The Film Roll On The Adjustment Sleeve It Cannot Be Loosened And Moved;

Loosen The Back Cap And Move Of The Blister Packaging Machine The Elastic Adjustment Nut To Align The Middle Of The Pvc Roll With The Middle Of The Heat-Sealing Roll (250Mm From The Machine Body). When Installing, Use A Steel Ruler To Measure The Inner Side Of The Roll 125Mm From The Machine Body;

Adjust The Tightness Of The Brake Screws. The Tension Of The Pvc Coil Is Adjusted To 0.5~1Kg Tension, And The Tension Of The Aluminum Foil Coil Is Adjusted To 1~2Kg Tension.

The Pvc Plastic Belt Placed On The Blister Packaging Machine Passes Through The Upper And Lower Heating Plate Molds To The Indexing Feed Roller And Presses On The Pressure Roller.

After The Temperature And Pressure Reach The Requirements, Press The Start Button of Blister Packaging Machine To Perform The Task. At This Time, The Equipment Will Start With A Delay Of 3 Seconds, And Then The Position Of The Indexing Feed Roller Should Be Adjusted According To The Blister Tape Formed By The Positive Pressure, So That The Blister Is Loaded Inside The Bubble Pocket Of The Feed Roller.
