ZP-41/55 Pill Tablet Press Machine

ZP-41/55 Pill Tablet Press Machine

The feeding system of the high speed tablet press machine can generally be divided into three types: the shoe feeding system of the single punching machine, the moon feeding system of the low speed rotary high speed tablet press machine, and the forced feeding part of the high speed press.

The system of the single high speed tablet press machine machine is compared with the structural characteristics of the stamping process. The main structure of the material system is that the feeding device is in the shape of a shoe, that is driven by the cam to swing left and right on the die surface to complete the operating of the feeding, scraping, and pushing.

The crescent gate feeding system of the ordinary low-speed rotary tablet press machines, the feeder is fixed on the turntable gauge, so that the lower part of the gate maintains a certain distance, with a template surface. When the rotating rings of the moulds pass under the feeder, the product particles on the grid fall into the mould holes, and the multiple twisted grid plates causes the product to be filled as multiple times.

The feeder of high speed tablet press machine machine process is that the particles are filled into the holes of the die, and when the downward die is pushed to the upper plane of the feed rail, the excess pellets are scraped off with a scraper; when the lower dies move forward to the upper edge of the wheel , when the upper dies move forward to the lower edge of the upper wheel, the distance between the two dies is the smallest, and the particles are compressed into flakes.

***  Technical parameter
