Pharmaceutical Blister Sheet Cartoning Machine
These are the highly intelligent PLC control automatic box packing machine which supervises everything of loading accurately. All these check points of all stations in cartoner packing machine freely shares all data and have mutual checks. This Cartoning Machine is quite smart because it can check product missing and will auto stop working at once. And it will auto run at once when there is nothing missing. This machine utilizes the raw material stainless steel or the nickel-chromium plated to make machine’s body and other spare parts.
*** Applications
*** Technical parameter
|
Model |
RQ-ZH-12OW |
|
Speed |
30-125 carton/min |
|
Total power |
0.750 KW |
|
Powersupply |
220/380V 50Hz |
|
Requirements of carton |
size range of carton:L(70-185)*W(35-90)*H(14-50)mm |
|
carton weight:250-350g/㎡ |
|
|
Requirements of instructions |
size range of instructions:L(78-250)*W(90-170)mm |
|
range of folding times of instructions:1-4 fold |
|
|
instructions weight:60-70g/㎡ |
|
|
Pressure |
pressureintensity:≥0.6MPa |
|
air consumption:120-160 L/min |
|
|
Overall size of machine |
4300*1100*1550㎜ |
|
Net weight of machine |
about1600kg |
***Configuration List
|
Item |
Specification |
Qty. |
Manufacturer |
|
Servo motor |
400W MHMD042G1U |
1 |
Panasonic |
|
Servodriver |
400W MBDHT2510E |
1 |
Panasonic |
|
Main motor |
R17DT80N41.1KW/220V/380V |
1 |
GermanySEW |
|
Vacuum pump |
VT4.40 |
1 |
BECKER |
|
Frequencyconverter |
FC-051P1K5S2E20H |
1 |
Danfoss |
|
Air circuit breaker |
DZ47-D63/2P |
1 |
Yaohua |
|
Air circuit breaker |
DZ47-D63/1P |
3 |
Yaohua |
|
Relay |
MY2NJ/24VDC |
8 |
Japan Omron |
|
Touch screen |
GC—4408W |
1 |
Proface |
|
Switch power supply |
NES-100-24V |
1 |
Taiwan MIWE |
|
Power switch |
T0-2-1/EA/SVB |
1 |
Germany Moeller |
|
PLC |
Smart ST40 |
1 |
Germany Siemens |
|
Fiber amplifier |
E3X-NA11 |
8 |
Japan Omron |
|
Optical fiber |
E32-ZD200 |
8 |
Japan Omron |
|
Encoder |
E6B2-CWZ6C |
1 |
Japan Omron |
|
Proximity switch |
TL-Q5MC1 |
1 |
Japan Omron |
|
Photoelectric switch |
D-73277 |
2 |
Germany LEUZE |
|
Photoelectric switch |
GTE6-N-1212 |
1 |
Japan Omron |
|
Solenoid valve |
VQ21A1-5G-C8 |
1 |
Japan SMC |
|
Filter pressure relief valve |
AW30-03E |
1 |
Japan SMC |
|
Solenoid valve |
VP342R-5GD1-02A |
1 |
Japan SMC |
|
Solenoid valve |
VP542R-5GD1-03A |
5 |
Japan SMC |
|
Solenoid valve |
VQ2321-5G1-02 |
4 |
Japan SMC |
|
Vacuum occur device |
ZH20DS-03-04-04 |
2 |
Japan SMC |
|
Silencer |
AN402-04 |
2 |
Japan SMC |
|
Sucker |
KPS6-WS |
10 |
Korea VTEC |
|
Cylinder |
CO20B20-10DC |
3 |
Japan SMC |
|
Pressure switch |
QPM11-N0 |
1 |
AEK |
|
Magnetic switch |
CS1-S |
1 |
AOTAI |
|
Emergency stop button |
ZB2-BE102C |
1 |
France Schneider |
***
This cartoning machine for bottle tube blister utilizes special technology of temper to ensure its zero toxicity, has zero corrosion and zero danger and is durable in it.
***
This machine for bottle tube blister has the setting of overload protection, and this setting has the double protection function to save the production cost and to protect the people’s safety.
***
And this machine for bottle tube blister has high accuracy of 100% when 120W is detecting products and no unqualified products would be allowed to pass the detection.
*** Certification: SGS, CE, ISO
***
This is a fast speed box carton packing machine and it can reach to the high working speed of 125 cartons per minute.
And it is very stable in the whole cartoning running.
This machine for bottle tube blister is better than the single servo motor equipment, because this machine can run quickly more stably and this is a significant advantage of the double servo motors.
