RQ-16Pro Capsule Tablet Counting Machine
Why are more and more pharmacies and pharmaceutical factories now using non-benchtop automatic capsule and tablet counting machines? Compared with the mechanical automatic counting machine used before, it can no longer fully meet the demand. Therefore, the medical low-speed, medium-speed and high-speed tablet and capsule counting machines developed by our company have been fully applied in the field of medicine.
At the same time, the price of capsules, tablets and pills sold in the pharmaceutical field and pharmacies is relatively high, so the accuracy of the capacity of a single bottle is very high. With close to 100% accuracy, our new automatic counting machine can count and fill 20 to 90 bottles in one minute. Why choose our DSL-16Pro electronic counter? At the same time, the intelligent PLC system no longer uses the outdated button control, but adopts the touch screen control, so that a wide range of technical upgrades have been carried out in terms of operation and convenience.
Not only that, we also take into account the objective needs of cleaning and maintenance, through one-button operation on the PLC touch screen, the replacement of different formulations and bottles can be completed within seconds. Combined with the modular architecture design, by adopting this method, each removable part can be fully maintained and cleaned, the work can be completed in a few minutes, and the service life of the automatic counting machine can be greatly improved.
*** Technical parameter
Model | RQ-DSL-16Pro |
Vibration groove tracks | 16 lane |
Production capacity | 40-90 bottles/min |
Accuracy rate | >99.97% |
Voltage | AC380V 3P 50/60HZ |
Power | 2.2KW |
Air consumption | 120L/min |
Hopper capacity | 45L |
weight | 650kg |
Outline dim.(mm) | 1200×1550×1750mm |
