ZP 17 Rotary Automatic Tablet Press Machine
The rotary tablet press ZP17D, which has undergone 7 technological transformations and upgrades, is now combined with our strong production and supply chain capabilities, namely 3-year free warranty, full-life warranty period and a short delivery period as short as 10 days. As the country's consumption level increases, we Rich Packing pay more and more attention to health, and the demands for the pharma Press Tablet Machine Automatic market is also greatly increasing.
When the pharmaceutical market welcomes better and better development, 17D will also promote the development of pharma related production equipment. Among all, the press pill machine automatic is one of the commonly using pharmaceutical machinery. With the fierce market competition and the new requirements of pharma companies for equipment, many pharmacy packaging machinery manufacturers are constantly testing, improving, upgrading the performance of the 17D automatic press tablet machine.
The turntable molds in the tablet pressing machine automatic chamber can also be quickly replaced and maintained. If customers need to produce products of different specifications, they can also change the molds within 10 minutes to achieve the effects of producing different tablets.
*** Technical parameter
Model |
ZP11D |
ZP15D |
ZP17D |
ZP19D |
ZP21D |
Dies No. |
11 |
15 |
17 |
19 |
21 |
Max. Pressure |
100kn |
80 kn |
60 kn |
60 kn |
60 |
Max. Dia. of Tablet |
40mm |
25 mm |
20 mm |
13 mm |
12 mm |
Max.DepthofFilling |
28 mm |
15 mm |
15 mm |
15 mm |
15 mm |
Max.Thickness of Tablet |
10 mm |
6 mm |
6 mm |
6 mm |
6 mm |
Rotary Speed |
20r/min |
30 r/min |
30 r/min |
30 r/min |
30 r/min |
Max. Production Capacity |
13200 pc/h |
27000 pc/h |
30600 pc/h |
34200 pc/h |
37800 pc/h |
Power |
3.0kw |
||||
voltage |
220v/380v |
||||
dimension |
890*650*1680mm |
||||
weight |
1000kg |
