ZP 26/50D Rotary High Speed Tablet Press Machine of Rich Packing
If you are looking for Rotary Tablet Press Machine Manufacturer in China which can save production manufacture space and have the perfect tablet pressing capability, then this ZP-26/50D tablet press from RICH PACKING Company is the best choice for you. Lots of customers find us to buy this machine model, many of them because the current machine they used cannot meet their demands, such as the production of tablets is not tight enough, and the tablets cause unknown causes of splicing.
Are you using a rotary tablet press to make a tablet and encountering a splinter? There would be several reasons for this:
Because the running pressure is too large, when the materials meets the pressure increase, then its expansion degree also increases, the strength of the adhesive can not stop the expansion directly caused by the blade, the treatment way is to reduce the working pressure of the machinery.
For the improper choice of adhesive slice, when granulating, the adhesive is too small, the viscosity is not enough after drying the particles, fine powder is too hard when too much dry pellets, can cause disintegrating difficulty, and one-sided point, so the addition of adhesive should be appropriate; If too much fine powder material, can screen out a little.
When the flakes are caused by the improper granules, loose the texture and too much fine powder, the concentration and the dosage of adhesive should be adjusted to improve the granulation method to overcome these problem. And when the pellet is too dry, containing crystal water drugs lose too much caused by the splinter, because according to different varieties should control the water content of the pellet.Our ZP-26/50D tablet press has eliminated the difficulty of the tablet splicing after years of special research and adjustment.
*** Technical parameter
Model |
ZP-26D |
ZP-32D |
ZP-40D |
ZP-50D |
Dies No. |
26 |
32 |
40 |
50 |
Max. Pressure |
Main 150 kn,Pre 16 kn |
|||
Max. Dia. of Tablet |
25 mm |
16 mm |
13 mm |
10 mm |
Max.Depth of Filling |
20 mm |
16 mm |
16 mm |
16 mm |
Max.Thickness of Tablet |
1-8 mm |
|||
Rotary Speed r/min |
10-110 |
|||
Max. Production Capacity pcs/hour |
170,000 |
210,000 |
260,000 |
330,000 |
Power |
7.5 kw |
7.5 kw |
7.5 kw |
7.5 kw |
voltage |
380 220V/50Hz |
380 220V/50Hz |
380 220V/50Hz |
380 220V/50Hz |
size |
820*1100*1750 mm |
820*1100*1750 mm |
820*1100*1750 mm |
820*1100*1750 mm |
Weight |
1660 kg |
1660 kg |
1660 kg |
1660 kg |
