8D Pill Counter Capsule Tablet Counting Machine By Rich Packing
The Why did our Rich Packing enterprise launch the 8D type machinery after have the two innovative models of tablet counting machines of 16R and 16H? The new small automatic tablet counter machine 8D developed by the RICH PACKING Group factory is based on cutting-edge technology.
The dsl-16h and the RQ dsl-16r that have been very popular in the world's major pharmacy and medical markets before, are the basis for the development of this 8D pill counting machine.The previous old capsule counting machine works in the following way. For example, the utility model discloses a capsule counting machine.
8D pill counter includes a loading hopper and a feeding chute and a control computer and a vibration device; it also includes a trapezoidal box and the discharge port and the glass turntable device and an electric eye device; The plc control computer and the vibration device are all located on the base; the feeding chute Located below the counting charging hopper; the glass turntable device communicates with the trapezoidal carton; The trapezoidal box is in communication with the discharging ports;
the glass turntable device is arranged on the base, located the below the side of the loading hopper and below the feeding chute; the glass turntable devices include a glass turntable and a track and the upper bracket of the glass turntable; the upper brackets of the glass turntable and the orbiter are both fixed on the glass turntable.The structure of the power system and electrical system of this 8D tablet counting machine are set inside the machinery, and the 8D outside is wrapped in stainless steel, which is very beautiful.
*** Technical parameter
|
Model |
RQ-DSL-8D |
|
Vibration groove tracks |
8 lane |
|
Production capacity |
50 bottles per minute (according to the capacity of 60 capsules per bottle) |
|
Accuracy rate |
＞99.97% |
|
Filling range |
3 ～ 9999 grains |
|
Applicable target |
Tablet:Φ3～25mm ,pill:Φ3～20mm, |
|
Applicable bottle type |
Φ25～75mm round and square bottle, height ≤240 mm |
|
Voltage |
AC380V 3P 50/60HZ |
|
Power |
1.5KW |
|
Pressure |
0.4～0.6Mpa |
|
Air consumption |
105L/min |
|
Hopper capacity |
25L |
|
Weight |
405kg |
|
Outline dim.(mm) |
1100×1400×1800mm（L*W*H） |
*** Configuration List
|
No. |
Item |
Specification |
Qty. |
Manufacturer |
|
1 |
Count Photoelectric Sensor (Receive) |
N24.5R |
8 |
Lattine |
|
2 |
Count Photoelectric Sensor (Emit) |
N24.5E |
8 |
Lattine |
|
3 |
Valve Group |
M4SB10-M5-6 |
1 |
Japan CKD |
|
4 |
Filtrate Regulator |
FR500 |
1 |
Taiwan SHAKO |
|
5 |
PLC Group |
FP∑-C32TH FPO-E16YT |
1 |
Japan Panasonic |
|
6 |
Touch Screen |
GE4408W |
1 |
Japan Pro-face |
|
7 |
Cable Diffuse Sensor |
QS18VN6DB |
3 |
USA.BANNER |
|
8 |
AC Contactor |
GMC-9 |
1 |
Korea LG |
|
9 |
DC Contactor |
GMD-9 |
3 |
Korea LG |
|
10 |
Thermal Overlood Relay |
GTH-22/3 |
1 |
Korea LG |
|
11 |
Count Cylinder |
SCPS2-1030 |
8 |
Japan CKD |
|
12 |
Position Cylinder |
SDA20-10 |
4 |
AIRTAC |
|
13 |
Control Box |
131200000 |
1 |
Germany MECANO |
|
14 |
Directive Signal Light |
AL6M-P |
3 |
Japan IDEC |
|
15 |
Button Switch |
ABW310EG |
1 |
Japan IDEC |
