Carton Box Packing Cartoner Automatic Cartoning Machine By Rich Packing
The promise of the honest after-sales service by RICH PACKING packaging machinery;
the installation and debugging of RICH Packing
After the quick transportation of the cartoning machine automatic arrives at your factory, our service team provides the on-site installation tasks and equipment debugging tasks for free, implements field training on the customer’s operations, and will provide applications and related technical materials to answer the various applications proposed by your group.
*** Applications
*** Technical parameter
|
Model |
RQ-ZH-12OL |
|
Speed |
35-125 carton/min |
|
Total power |
1.10 KW |
|
Powersupply |
220/380V 50Hz |
|
Requirements of carton |
size range of carton:L(65-150)*W(35-85)*H(12-45)mm |
|
carton weight:240-360g/㎡ |
|
|
Requirements of instructions |
size range of instructions:L(78-250)*W(85-170)mm |
|
range of folding times of instructions:1-4 fold |
|
|
instructions weight:60-70g/㎡ |
|
|
Pressure |
pressureintensity:≥0.6MPa |
|
air consumption:120-160 L/min |
|
|
Overall size of machine |
2150*1140*1800㎜ |
|
Net weight of machine |
about1500kg |
*** Configuration
|
Item |
Specification |
Qty. |
Manufacturer |
|
Servo motor |
400W MHMD042G1U |
1 |
Panasonic |
|
Servodriver |
400W MBDHT2510E |
1 |
Panasonic |
|
Main motor |
R17DT80N40.75KW/220V/380V |
1 |
GermanySEW |
|
Frequencyconverter |
FC-051P1K5S2E20H |
1 |
Danfoss |
|
Air circuit breaker |
DZ47-D63/2P |
1 |
Yaohua |
|
Air circuit breaker |
DZ47-D63/2P |
3 |
Yaohua |
|
Relay |
MY2NJ/24VDC |
5 |
Japan Omron |
|
Touch screen |
GC—4408W |
1 |
Proface |
|
Switch power supply |
NES-100-24V |
1 |
Taiwan MIWE |
|
Power switch |
T0-2-1/EA/SVB |
1 |
Germany Moeller |
|
PLC |
Smart ST40 |
1 |
Germany Siemens |
|
Fiber amplifier |
E3X-NA11 |
2 |
Japan Omron |
|
Optical fiber |
E32-ZD200 |
2 |
Japan Omron |
|
Encoder |
E6B2-CWZ6C |
1 |
Japan Omron |
|
Proximity switch |
1M12-4NNS |
1 |
Germany SICK |
|
Photoelectric switch |
D-73277 |
2 |
Germany LEUZE |
|
Photoelectric switch |
GTE6-N-1212 |
1 |
Japan Omron |
|
Solenoid valve |
VQ21A1-5G-C8 |
3 |
Japan SMC |
|
Solenoid valve |
VP342R-5GD1-02A |
2 |
Japan SMC |
|
Solenoid valve |
VP542R-5GD1-03A |
5 |
Japan SMC |
|
Solenoid valve |
VQ2321-5G1-02 |
4 |
Japan SMC |
|
Vacuum occur device |
ZH20DS-03-04-04 |
2 |
Japan SMC |
|
Silencer |
AN402-04 |
2 |
Japan SMC |
|
Sucker |
KPS6-WS |
10 |
Korea |
|
Cylinder |
CO20B20-10DC |
3 |
Japan SMC |
|
Pressure switch |
QPM11-N0 |
1 |
AEK |
|
Magnetic switch |
CS1-S |
1 |
AOTAI |
|
Emergency stop button |
ZB2-BE102C |
1 |
France Schneider |
***
RICH Packing's after-sales service promise
The superb after-sales service team is always online to deal with the user’s problems in using the cartoning machine and prevent machinery accidents at the fastest speed.
***
The spare parts that are in need of operation are guaranteed for three year. Once judged as quality Problem accessories, will provide free replacement and life-long protection.
***
The lifetime warranty means that RICH PACKING only charges labor costs when repairing oversea in the warranty period, and provides free spare parts and technical supports throughout the machine life.
*** Certification: SGS, CE, ISO
***
RICH PACKING we actually provides after-sales service and a 22-hour free service hotline.
After the same problem is determined, if necessary, our technicians must arrive at the filed at the fastest speed (the fastest flight scheduled on the day that the visa is issued) to deal with machine problems.
The machine’s quantity warranty is actually promised. During this warranty period, if there are machinery failures (except consumable parts) caused by non-remuneration, our company will repair or change the equipment for free. Once the cartoning machine is sold, the warranty period will be long for 36 months (except consumables).
