RQ-16B Capsule Counting Tablet Counting Machine By Rich Packing
Why are more and more medical pharmacies now using non-tabletop automatic capsules and tablets counting machines? As many people pay more and more attention to the concepts of the health and body maintenance, the number of one bottle and the number of bottles that pharmacies needed to count is getting higher and higher. Compared with the tabletop automatic counting machine used before, it is no longer able to fully meet the demand. So our company's the low-speed, medium-speed and high-speed tablet capsules counting machine medical developed for this kind of demand is fully using in the pharmaceutical field.
Generally speaking, the capsules and tablets pills sold in the pharmaceutical field and the pharmacies are relatively expensive, so the accuracy of the single bottle volume is very well. Our the new automatic counting machine has a precision of 100%, and it can count and fill from 20 to 100 bottles within one minute. Why you should choose ours’ DSL-16B electronic counter?At the mean time, the wide range of the technical changes and the innovations have been carried out in terms of the operation and the convenience. The outdated button control is no longer used in but the touch screen control of the intelligent PLC system is adopted.
Not only of that we also took into the account objective needs of the cleaning and the maintenance, and the removal and the installation of the tablets counting machine can be completed in 3 minutes. In this method, every detachable parts can be completely maintained and cleaned, and the machine service life of the automatic counting machines have been greatly improved.
*** Technical parameter
Production capacity |
20~105 bottles/min |
accuracy rate |
>99.8% |
Applicable target |
#000-5 capsule, soft capsule, Ø3-25 tablet,shaped,sugarcoated tablet, pill |
Filling range |
1-9999 grains (tablets) adjustable |
Applicable bottle type |
10-500ml round, square bottle |
voltage |
380/220V 50Hz |
power |
1.2KW |
pressure |
0.6Mpa |
gas consumption |
36~45L/min |
weight |
550kg |
Outline dim.(mm) |
1600×1650×1500mm |
*** Configuration
No. |
Item |
Qty. |
Manufacturer |
1 |
Motor |
1 |
Taiwan TQG |
2 |
Counting photoelectric head |
1 |
Taiwan |
3 |
Bottle photoelectric eye |
1 |
Panasonic |
4 |
Button |
1 |
Schneider |
5 |
Touch screen |
1 |
Siemens |
6 |
CPU |
1 |
ST |
7 |
Power |
1 |
Schneider |
8 |
Pneumatic elements |
1 |
Shanghai |
9 |
earth leakage protection |
1 |
Schneider |
