8 Passage Capsule Tablet Counting Machine
The drug dust is large, how does our RICH PACKING counting machine solve it? Vibration feeding mechanism (corrugated plate) dust filter: fully sealed cover with multi-air suction design and dust collector. Dust removal at the filling funnel mouth: adopt electrostatic mesh type dust removal device. The high-dust-resistant technology sensor is used to ensure stable and reliable use in a multi-dust state, and the counting accuracy is not affected.
How does our electronic counting machine solve the problem of debris? The product is equipped with a debris detection system as standard, and debris and lack of material will be automatically removed.
For bottles of different specifications, the filling mouth may need to be replaced. Our filling funnel adopts a modular design and a one-button lifting design. When it is necessary to replace the mold during the use of the electronic particle counting machine, the replacement is convenient and quick, and any person can complete the replacement.
At present, there are many specifications of automatic tablet counting machines. As far as possible, choose equipment that can count different types of products. 12-channel automatic electronic tablet counting machine, capsule counting machine, tablet and pill counting machine, 16-channel automatic tablet and capsule electronic The tablet counting machine does not need to change the mold to count different types of capsule tablets, 48-channel secondary electronic tablet counting machine, automatic electronic tablet counting machine, etc. Customers can choose according to their own production needs and affordable price range.
*** Technical parameter
|
Model |
RQ-DSL-8D |
|
Vibration groove tracks |
8 lane |
|
Production capacity |
50 bottles per minute (according to the capacity of 60 capsules per bottle) |
|
Accuracy rate |
＞99.97% |
|
Filling range |
3 ～ 9999 grains |
|
Applicable target |
Tablet:Φ3～25mm ,pill:Φ3～20mm, |
|
Applicable bottle type |
Φ25～75mm round and square bottle, height ≤240 mm |
|
Voltage |
AC380V 3P 50/60HZ |
|
Power |
1.5KW |
|
Pressure |
0.4～0.6Mpa |
|
Air consumption |
105L/min |
|
Hopper capacity |
25L |
|
Weight |
405kg |
|
Outline dim.(mm) |
1100×1400×1800mm（L*W*H） |
*** Configuration List
|
No. |
Item |
Specification |
Qty. |
Manufacturer |
|
1 |
Count Photoelectric Sensor (Receive) |
N24.5R |
8 |
Lattine |
|
2 |
Count Photoelectric Sensor (Emit) |
N24.5E |
8 |
Lattine |
|
3 |
Valve Group |
M4SB10-M5-6 |
1 |
Japan CKD |
|
4 |
Filtrate Regulator |
FR500 |
1 |
Taiwan SHAKO |
|
5 |
PLC Group |
FP∑-C32TH FPO-E16YT |
1 |
Japan Panasonic |
|
6 |
Touch Screen |
GE4408W |
1 |
Japan Pro-face |
|
7 |
Cable Diffuse Sensor |
QS18VN6DB |
3 |
USA.BANNER |
|
8 |
AC Contactor |
GMC-9 |
1 |
Korea LG |
|
9 |
DC Contactor |
GMD-9 |
3 |
Korea LG |
|
10 |
Thermal Overlood Relay |
GTH-22/3 |
1 |
Korea LG |
|
11 |
Count Cylinder |
SCPS2-1030 |
8 |
Japan CKD |
|
12 |
Position Cylinder |
SDA20-10 |
4 |
AIRTAC |
|
13 |
Control Box |
131200000 |
1 |
Germany MECANO |
|
14 |
Directive Signal Light |
AL6M-P |
3 |
Japan IDEC |
|
15 |
Button Switch |
ABW310EG |
1 |
Japan IDEC |
