NJYF 300C Capsule Filling Machine By Rich Packing
This capsule sealing machine oil liquid is suitable for filling liquid materials into hard shell empty capsules, for filling the liquid type thins as solutions, suspensions,oily liquids, all the pastes can be filled into the number 00 to number 3 # gelatin capsules or the vegetable type capsules. 300C’s accurate filling rate are (+ -, 1-2%), with meeting GMP production requirements function , and 300 type highly output 18,000 grains/hour.
*** Applications
*** Technical parameter
|
Production capacity |
300pcs/min |
|
Net weight of machine |
750KG |
|
Overall size of machine |
860*960*1800mm |
|
Power |
380V 50Hz |
|
Total power |
5KW |
|
No.of segment bores |
6 |
|
Noise |
<75DB(A) |
|
Making rate |
Empty capsule 99.9% Full capsule 99.8% |
|
Filling error |
≤2% |
|
Applicable product |
00-3# gelatin capsule, methyl cellulose, plant capsule |
*** Configuration
|
Item |
Specification |
Qty. |
Manufacturer |
|
Touch screen |
6AV6648-0BC11-3AX0 |
1 |
Germany Siemens |
|
PLC |
6ES7/288-1ST30-0AA0 |
1 |
Germany Siemens |
|
Frequency converter |
MODECVFD015 B21A |
2 |
Taiwan Delta |
|
Intermediate relay |
MY2NJ |
2 |
Omron |
|
AC Contactor |
3TB42 |
4 |
SIEMENS |
|
Switch |
S-50-24 |
1 |
Taiwan Mingwell |
|
Main Motor |
R37DM90LS4 |
2 |
Germany SEW |
|
Servo Motor |
SGM7J-04AFC6S |
2 |
Japan Yaskawa |
|
Vacuum pump（dry） |
KRX3-P-VB-03 |
1 |
Japan Orion |
|
Detection optical fiber |
FS-N18N |
4 |
Japan Keyence |
|
Ceramic pump |
0.2-0.5ML |
2 |
Shenzhen |
|
Transmission bearing |
Bearing |
90 |
Japan |
|
Cam |
RU-63DS10 |
1 |
Taiwan Safepower |
Here is the main features of the NJYF 300C capsule machine liquid filling.
Using imported Japan Yaskawa brands high-precision servo motor, with the high precision rate of liquid filling injection and these error more than 2%.
*** NJY-300C’s High-precision detection system
300C Adopt multi ceramic pump to cut the material, these will solve the problem of the thick material cutting situation.
*** NJY-300C’s high quality materials
The infrared ray detects liquid filling whether the capsule cap body is separated, when there is no separation and system is automatically rejected without adding liquid.
*** Why choose ours NJY-300C model?
300C's Strong versatility with No. 0-#3 capsule air-drying system does not need to replace all the mold separately that can saves much time.
The design of the machine’s turntable has obtained the utility model national patents, and the double-sealed design is adopted to prevent liquid oil butter from entering the interior of the turntable.
The transversal double shaft of the capsuling liquid filling machine turntable adopts Teflon oil-free bearings, so there is no need to refuel for life.
