Specially Counting Sweets Candy Counter Machine By Rich Packing
Our Guangdong RICH PACKING smart counting machine automatic is specially designed for these materials that with sticky surfaces. Especially for the most popular western countries and regions viscous candy counting bottling bags have been patented and promote solutions, including the most representative pectin gummies, cube sugar on the surface, and the coated candy with oil on the surface, and etc..
The advantages of our Guangdong RICH PACKING sweets candy counting machine:
These machine has a built-in intelligent running management system, that improves the production capacity of counting bottling and bagging greatly;
The materials hopper is equipped with a movement cylinder device to use for the separation of the candy, which helps the gummy to obtain a good loose distribution before into the vibration channel effectively;
Compared with the other ordinary machines, the vibration groove is sprayed with the Teflon material, it will make the candy move without lag very smoothly.
The blanking bottle device is made form PTFE, it also meets the cGMP standards and will not be blocked never;
The bottling mouth adopts the highly sensitive cylinder vibration blanking device and technology, and the bottle will never be blocked when the pectin gummy is bottled and bagged;
The above various parts and the counting parts for improving gummy candy counting machine help customers reduce the dependence on labor and save costs greatly; make all links of packing connected closely, accurate counting, saving time and saving effort; automatic adjustment by PLC smart system can be flexibly adjusted the candy products of all shapes, sizes and textures, to meet a variety of packaging ways.
*** Technical parameter
|
Model |
RQ-DSL-16R |
|
vibration groove tracks |
16 lane |
|
Production capacity |
200,000 ～ 360,000 grains/h |
|
accuracy rate |
＞99.97% |
|
Filling range |
3 ～ 9999 grains |
|
Applicable target |
Tablet:Φ3～25 mm ,pill:Φ3～20 mm, |
|
Applicable bottle type |
Φ25～75 mm round and square bottle, height ≤240 mm |
|
voltage |
AC380V 3P 50 / 60HZ |
|
power |
2.2 KW |
|
pressure |
0.4～ 0.6 Mpa |
|
Air consumption |
120 L/min |
|
Hopper capacity |
45 L |
|
weight |
650 kg |
|
Outline dim.(mm) |
1200×1550×1750 mm |
*** Configuration List
|
No. |
Item |
Specification |
Qty. |
Manufacturer |
|
1 |
Count Photoelectric Sensor (Receive) |
N24.5R |
16 |
Lattine |
|
2 |
Count Photoelectric Sensor (Emit) |
N24.5E |
16 |
Lattine |
|
3 |
Valve Group |
M4SB10-M5-6 |
2 |
Japan CKD |
|
4 |
Filtrate Regulator |
FR500 |
1 |
Taiwan SHAKO |
|
5 |
PLC Group |
FP∑-C32TH FPO-E16YT |
1 |
Japan Panasonic |
|
6 |
Touch Screen |
GE4408W |
1 |
Japan Pro-face |
|
7 |
Cable Diffuse Sensor |
QS18VN6DB |
3 |
USA.BANNER |
|
8 |
AC Contactor |
GMC-9 |
1 |
Korea LG |
|
9 |
DC Contactor |
GMD-9 |
3 |
Korea LG |
|
10 |
Thermal Overlood Relay |
GTH-22/3 |
1 |
Korea LG |
|
11 |
Count Cylinder |
SCPS2-1030 |
16 |
Japan CKD |
|
12 |
Position Cylinder |
SDA20-10 |
4 |
AIRTAC |
|
13 |
Control Box |
131200000 |
1 |
Germany MECANO |
|
14 |
Directive Signal Light |
AL6M-P |
3 |
Japan IDEC |
|
15 |
Button Switch |
ABW310EG |
1 |
Japan IDEC |
